Fruit Pulp Conical Drum

Our fruit pulp conical drum has a bottom that handles heavy loads. Fruit pulp has high density. Each drum weighs much more than a drum of regular liquid. The bottom takes the most pressure. We optimized our bottom rib reinforcement process through many tests. We added a rib-forming station to our bottom mold design. The ribs are formed in one stamping step. This adds no extra welds. Every batch of reinforced bottoms goes through a load test. This ensures the bottom does not deform during stacking and handling. Our fruit pulp conical drum has a capacity of 220 liters. The wall thickness is not less than 1.0 millimeter.

The inner coating on our fruit pulp conical drum uses food-grade EPF material. It passes a spark pinhole test. This confirms there are no pinholes or defects. The coating protects your pulp from direct contact with steel. The bottom has reinforced ribs. These ribs handle the weight pressure of high-viscosity fruit pulp. The open-top ring structure lets you remove the lid easily. You can reach inside with tools to discharge the pulp. Cleaning is also very convenient. The food-grade silicone gasket provides a reliable seal. We performed a 3-meter stacking test for 24 hours. The body and bottom showed no deformation. Our fruit pulp conical drum stacks well in warehouses and containers.

Our factory has 3 electrostatic spray painting lines and 2 automatic seam welders. Our equipment is worth over 10 million yuan. Our monthly production capacity is about 30,000 drums. Before accepting orders, our sales, production, procurement, and logistics teams conduct a joint review. This ensures on-time delivery. We support OEM and ODM customization for our fruit pulp conical drum. MOQ is 2,000 units. Free samples are available. Mass production takes about 10 days. Custom sample development takes about three months. The outer surface has an anti-rust paint coating.
